口環密封對多級離心泵濕轉子橫-軸雙向耦合動特性的影響

周文杰; 王孝軍; 邱寧; 王樂勤; 高波

doi:10.13374/j.issn2095-9389.2018.12.013

口環密封對多級離心泵濕轉子橫-軸雙向耦合動特性的影響

doi: 10.13374/j.issn2095-9389.2018.12.013

周文杰^1, ,,
王孝軍¹,
邱寧²,
王樂勤³,
高波^1,4

1) 江蘇大學能源與動力工程學院, 鎮江 212013
2) 江蘇大學流體機械工程技術研究中心, 鎮江 212013
3) 浙江大學能源工程學院, 杭州 310027
4) 北卡羅萊納州立大學機械與宇航工程系, 羅利 27606

基金項目:

國家自然科學基金資助項目（51706087）

詳細信息

中圖分類號: TQ051.1
計量
- 文章訪問數: 743
- HTML全文瀏覽量: 218
- PDF下載量: 15
- 被引次數: 0
出版歷程
- 收稿日期: 2017-12-27

Effect of annular seal on the lateral-axial bi-direction coupled dynamic characteristics of a multi-stage pump wet rotor

1) School of Energy and Power Engineering, Jiangsu University, Zhenjiang 212013, China
2) Research Center of Fluid Machinery Engineering and Technology, Jiangsu University, Zhenjiang 212013, China
3) Institute of Process Equipment, Zhejiang University, Hangzhou 310027, China
4) Department of Mechanical and Aerospace Engineering, North Carolina State University, Raleigh 27606, USA

摘要

摘要: 為探究口環密封對多級離心泵轉子橫-軸雙向耦合振動的影響，基于空間歐拉角變換及有限元法，建立了多級離心泵轉子系統葉輪和軸系的微分運動方程，在此基礎上，充分考慮口環流體激振力和多種軸向力的耦合作用，利用矩陣運算方法建立了多級離心泵濕轉子的橫-軸雙向耦合振動模型，并采用Newmark法對雙向耦合系統的瞬態動力學特性進行求解，重點研究了口環密封長度、壓差和間隙對系統耦合振動特性的變化規律，計算了不同密封參數下的流體激振力.計算結果表明，口環密封對轉子系統橫向振動的洛馬金效應隨著密封長度和壓差的增大以及間隙的減小愈發明顯，轉子系統的橫向穩態振動收斂速度快于軸向穩態振動的收斂速度，兩向瞬態振動的振動頻率呈現出完全不同的特性.此外，密封的流體激振力與密封長度呈現非線性變化關系，而與密封壓差和間隙呈現線性變化關系.
- 多級離心泵 /
- 濕轉子系統 /
- 雙向耦合振動 /
- 瞬態特性 /
- 軸向力
Abstract: Because of the increasingly rigid and complex operating conditions for multi-stage pumps, the annular seal is playing an important role in determining the dynamic characteristics of a rotor system. The annular seal can prevent fluid leakage to ensure that the pump system can satisfy the design requirements, such as the head and efficiency. However, the fluid-induced force that is caused inside the annular seal by the pressure reduction and nonconcentric motion directly acted on the rotor system, which presents transient characteristics with a variation in the operating conditions. Based on the Euler angle transformation and the finite element method, the differential equations of motions for impeller and shaft were determined in this study, and the coupled effects, including the fluid-induced force of the annular seal and multiple axial forces, were considered. These equations of motions and coupled effects were conducted to investigate the effect of the annular seal on the lateral-axial bi-direction coupled vibration for a multi-stage pump rotor system. Finally, the lateral-axial bi-direction coupled vibration model for a multi-stage pump wet rotor was integrated with the matrix operation,and the corresponding coupled transient dynamics were solved using the Newmark method. The changing rules of the coupled vibration characteristics and fluid-induced force were mainly investigated for different sealing lengths, pressure drops, and clearances. The calculated results imply that the influence of the annular seal on the Lomakin effect for rotor lateral vibration becomes increasingly obvious with increasing length and pressure drop and with decreasing clearance. The convergence rate for the lateral vibration is observed to be faster than that for the axial vibration, and the vibration frequencies for the lateral-axial bi-direction presents different features. Furthermore, the fluid-induced force between the sealing lengths presents a nonlinear relation, whereas that between the pressure drop and clearance exhibits a linear relation.
- multi-stage pump /
- wet rotor system /
- bi-direction coupled vibration /
- transient characteristics /
- axial force

HTML全文

參考文獻(16)

[2]	Childs D W. Dynamic analysis of turbulent annular seals based on hirs' lubrication equation. J Lubr Technol, 1983, 105(3):429
[3]	Childs D W. Finite-length solutions for rotordynamic coefficients of turbulent annular seals. J Lubr Technol, 1983, 105(3):437
[4]	Childs D W. Rotordynamic moment coefficients for finite length turbulent seals//Proceedings of the IFTOMM Conference. Rome, 1982:371
[5]	Nelson C C, Nguyen D T. Analysis of eccentric annular incompressible seals:Part 1-a new solution using fast Fourier transforms for determining hydrodynamic force. J Tribol, 1988, 110(2):354
[6]	Nelson C C, Nguyen D T. Analysis of eccentric annular incompressible seals:Part 2-effects of eccentricity on rotordynamic coefficients. J Tribol, 1988, 110(2):361
[7]	Marscher W D. Analysis and test of multistage pump "wet" critical speeds. Tribol Trans, 1991, 34(3):445
[8]	Jiang Q L, Zhai L L, Wang L Q, et al. Fluid-structure interaction analysis of annular seals and rotor systems in multi-stage pumps. J Mech Sci Technol, 2013, 27(7):1893
[9]	Wang L Q, Zhou W J, Wei X S, et al. A coupling vibration model of multi-stage pump rotor system based on FEM. Mechanika, 2016, 22(1):31
[10]	American Petroleum Institute. ANSI/API Standard 610 Centrifugal Pumps for Petroleum, Petrochemical and Natural Gas Industries. Washington:API Publishing, 2010
[11]	Chen L W, Peng W K. The stability behavior of rotating composite shafts under axial compressive loads. Compos Struct, 1998, 41(3-4):253
[12]	Young T H, Shiau T N, Kuo Z H. Dynamic stability of rotorbearing systems subjected to random axial forces. J Sound Vib, 2007, 305(3):467
[13]	Yim K B, Yim J. Dynamic behavior of overhung rotors subjected to axial forces. Int J Precis Eng Manuf, 2012, 13(9):1575
[14]	Yim K B, Yim J T. Dynamic stability of a rotor with shear-flexible shaft under axial loads. J Mech Sci Technol, 2013, 27(2):359
[16]	Zou D L, Rao Z S, Ta N. Coupled longitudinal-transverse dynamics of a marine propulsion shafting under superharmonic resonances. J Sound Vib, 2015, 346:248
[17]	Zou D L, Liu L, Rao Z S, et al. Coupled longitudinal-transverse dynamics of a marine propulsion shafting under primary and internal resonances. J Sound Vib, 2016, 372:299
[23]	Gong R Z, Wang H J, Zhao J L, et al. Influence of clearance parameters on the rotor dynamic character of hydraulic turbine shaft system. Proc Inst Mech Eng C-J Mech Eng Sci, 2013, 228(2):262
