Design and analysis of a series of new SST-LEJ based on tension straps
-
摘要: 設計了一種基于大柔度的柔性鉸鏈,命名為SS-LEJ,利用等效法推導了其彎曲等效剛度的理論計算公式,通過設計實例的理論計算和ABAQUS仿真分析,驗證理論計算公式的正確性.為了有效提升SS-LEJ的抗拉壓性能,設計了4種不同位置和形狀的拉力帶的SST-LEJ,通過彎曲性能和抗拉壓性能的有限元仿真分析,得出SST3-LEJ和SST4-LEJ為4種SST-LEJ當中整體性能較優的兩種.將SST3-LEJ和SST4-LEJ與SS-LEJ、Inverted Bending-Orthogonal鉸鏈進行了彎曲性能和抗拉壓性能的比較,得出SST3-LEJ和SST4-LEJ的彎曲性能介于SS-LEJ和Inverted Bending-Orthogonal鉸鏈之間,抗拉壓性能優于SS-LEJ和Inverted Bending-Orthogonal鉸鏈,說明SST3-LEJ和SST4-LEJ的整體性能較好,達到了預期的設計目的,為大柔度柔性鉸鏈的設計提供了一種思路.Abstract: Lamina emergent mechanisms that can realize out-of-plane motion are a kind of compliant mechanisms. They mainly transmit motion, force, and energy through flexible joints; therefore, the design of flexible joints is very important. In the design of flexible joints, the primary requirements are the bending performance and the tensile and compressive properties. However, in general, with the improvement of the bending performance of flexible joints, the tensile and compressive properties deteriorate, and the overall performance of the joints is unable to meet the requirements. To realize joints with better overall performance, tension straps of flexible joints were designed in this study. Based on a flexible joint with high flexibility, a new flexible joint named SS-LEJ was designed. According to the equivalent method, the joint's equivalent spring model was created, and the equations needed to calculate the bending equivalent stiffness of the joints were deduced. In addition, a finite element analysis model was created. The equations were verified by theoretical calculations and ABAQUS simulation analysis. The theoretical calculation and ABAQUS simulation analysis results agree very well. To improve the tensile and compressive properties of SS-LEJ, four kinds of tension straps in different positions and shapes of SST-LEJ were designed. Stress analysis was performed, and the finite element analysis results show that SST3-LEJ and SST4-LEJ are the best two kinds of SST-LEJ. The bending performances and the tensile and compressive properties of SST3-LEJ, SST4-LEJ, SS-LEJ, and inverted bending-orthogonal (IBO) joint were compared. The results show that the bending performances of SST3-LEJ and SST4-LEJ are between those of SS-LEJ and IBO joint, and the tensile and compressive properties of SST3-LEJ and SST4-LEJ are better than those of SS-LEJ and IBO joint. This indicates that the overall performances of SST3-LEJ and SST4-LEJ are better, and the design goal is achieved, which provides an effective method for the design of flexible joints.
-
參考文獻
[1] Uicker J J, Pennock G R, Shigley J E. Theory of Machines and Mechanisms. 4th Ed. Oxford:Oxford University Press, 2011 [2] Howell L L. Compliant Mechanisms. New York:John Wiley&Sons Inc, 2001 [3] Smith S T. Flexures:Elements of Elastic Mechanisms. CRC Press, 2000 [4] Lobontiu N. Compliant Mechanisms:Design of Flexure Hinges. CRC Press, 2003 [5] Jacobsen J O, Howell L L, Magleby S P. Components for the design of lamina emergent mechanisms//ASME 2007 International Mechanical Engineering Congress and Exposition. Seattle, 2007:165 [6] Jacobsen J O, Winder B G, Howell L L, et al. Lamina emergent mechanisms and their basic elements. J Mechanisms Robotics, 2010, 2(1):01003 [7] Zirbel S A, Trease B P, Magleby S P, et al. Deployment methods for an origami-inspired rigid-foldable array//Proceedings of the 42nd Aerospace Mechanisms Symposium. NASA Goddard Space Flight Center, 2014:189 [8] Aten Q T, Jensen B D, Burnett S H, et al. A self-reconfiguring metamorphic nanoinjector for injection into mouse zygotes. J Rev Sci Instrum, 2014, 85(5):055005-1 [16] Wilding S E, Howell L L, Magleby S P. Spherical lamina emergent mechanisms. Mechanism Machine Theory, 2012, 49:187 [17] Jacobsen J O, Chen G M, Howell L L, et al. Lamina emergent torsional (LET) joint. Mechanism Machine Theory, 2009, 44(11):2098 [18] Aten Q T, Jensen B D, Howell L L. Geometrically non-linear analysis of thin-film compliant MEMS via shell and solid elements. Finite Elem Anal Des, 2012, 49(1):70 [21] Delimont I L, Magleby S P, Howell L L. A family of dual-segment compliant joints suitable for use as surrogate folds. J Mech Des, 2015, 137(9):092302 [23] Chen G M, Howell L L. Two general solutions of torsional compliance for variable rectangular cross-section joints in compliant mechanisms. Precis Eng, 2009, 33(3):268 -
