Erosion-corrosion behavior of L80 steel under high velocity wet gas condition by flow loop method
-
摘要: 利用高溫高壓濕氣環路研究了L80鋼在高氣相流速濕氣環境中的腐蝕-沖蝕行為.利用腐蝕失重法測試了L80掛片在氣速30 m·s-1,含水率0.0007%,CO2分壓0.5 MPa及55℃的工況下,分別在不同的腐蝕周期下的腐蝕速率.利用激光共聚焦顯微鏡對試樣表面形貌進行了觀察,利用掃描電子顯微鏡對腐蝕產物形貌進行觀察,利用X射線衍射及能譜儀對腐蝕產物組成進行了分析.結果表明,L80鋼在高氣相流速濕氣環境下腐蝕失重嚴重,腐蝕后試樣表面出現大量的微小蝕坑,隨著實驗周期的延長蝕坑會不斷長大.該工況下產生的腐蝕產物主要成分為Fe3C和FeCO3.Abstract: With the continuous petroleum extraction from deep-water subsea gas fields, many long distance offshore natural gas pipelines have been constructed. The design parameters directly affect the gas flow velocity in pipelines, which may introduce high wall shear stresses on the pipeline internal wall. Moreover, corrosive medium like CO2, H2S, O2, and Cl- always exists in subsea pipelines under high velocity gas flow, which induces erosion-corrosion. Many pipelines in China have entered the middle or late stage of service, and this has increased the risks and failures induced by erosion-corrosion. Furthermore, more natural gas storages are being built for transportation, which require a high-velocity gas flow for gas injection and production processes. A certain amount of corrosive mediums such as residual drilling fluid, hydrochloric acid, condensate water, CO2, and H2S can be found in natural gas, and when combined with a high gas flow velocity, internal erosion-corrosion might occur in the tubing in downhole systems. In this study, a high temperature-high pressure flow loop was applied to investigate the corrosion behavior of L80 steel in a wet gas pipeline with a high gas velocity. The extreme conditions created by the flow loop is 30 m·s-1 gas velocity, 0.0007% water cut, 0.5 MPa CO2 partial pressure, and 55℃ environmental temperature. Corrosion rates at different testing periods were calculated through weight-loss measurements. Confocal laser scanning microscopy and scanning electron microscopy were applied to observe the corrosion morphology. The corrosion product constituents were analyzed using X ray diffraction and energy dispersive spectroscopy (EDS), and the results reveal that severe corrosion occurs and a large number of micro pits appear on the L80 coupons surfaces. Moreover, instead of an integral corrosion prod-uct film, FeCO3 corrosion product chips and Fe3C are present on the steel.
-
Key words:
- carbon steel /
- flow loop /
- high speed gas /
- wet gas /
- localized corrosion
-
參考文獻
[2] Zhang Z, Hinkson D, Singer M, et al. A mechanistic model of top-of-the-line corrosion. Corrosion, 2007, 63(11):1051 [3] Albertini C, Fernández S, Muñoz L G, et al. Advanced process simulation and erosion-corrosion modeling applied to material selection and fitness for service of gas production wells//CORROSION 2012. Salt Lake City, 2012:ArtNo. NACE-2012-1255 [4] Malka R, Nešić S, Gulino D A. Erosion-corrosion and synergistic effects in disturbed liquid-particle flow. Wear, 2007, 262(7-8):791 [5] Schmitt G, Bakalli M. Advanced models for erosion corrosion and its mitigation. Mater Corros, 2008, 59(2):181 [6] Salam M M. An alternative to API 14E erosional velocity limits for sand-laden fluids. J Energy Resour Technol, 2000, 122:71 [7] Zheng Z B, Zheng Y G. Erosion-enhanced corrosion of stainless steel and carbon steel measured electrochemically under liquid and slurry impingement J Corros Sci, 2016, 102:259 [8] Ruzic V, Veidt M, Nešić S. Protective iron carbonate films-Part 3:Simultaneous chemo-mechanical removal in single-phase aqueous flow. Corros, 2007, 63(8):758 [9] Sun Y, Hong T, Bosch C. Carbon dioxide corrosion in wet gas annular flow at elevated temperature. Corrosion, 2003, 59(8):733 [10] McLaury B S, Shirazi S A. An alternate method to API RP 14E for predicting solids erosion in multiphase flow. J Energy Resour Technol, 2000, 122:115 [11] Edwards J K, McLaury B S, Shirazi S A. Modeling solid particle erosion in elbows and plugged tees. J Energy Resour Technol, 2001, 123:277 [12] Papavinasam S, Revie R W, Attard M, et al. Comparison of laboratory methodologies to evaluate corrosion inhibitors for oil and gas pipelines. Corrosion, 2003, 59(10):897 [13] Efird K D, Wright E J, Boros J A, et al. Correlation of steel corrosion in pipe flow with jet impingement and rotating cylinder tests. Corrosion, 1993, 49(12):992 [14] Heuer J K, Stubbins J F. Microstructure analysis of coupons exposed to carbon dioxide corrosion in multiphase flow. Corrosion, 1998, 54(7):566 [15] Crolet J L, Thevenot N, Nesic S. Role of conductive corrosion products on the protectiveness of corrosion layers. Corrosion, 1998, 54(3):194 [16] Varela F E, Kurata Y, Sanada N. The influence of temperature on the galvanic corrosion of a cast iron-stainless steel couple (prediction by boundary element method). Corros Sci, 1997, 39(4):775 -
