變渣皮厚度條件下銅冷卻壁應力分布規律及掛渣穩定性

李峰光; 張建良

doi:10.13374/j.issn2095-9389.2017.03.011

變渣皮厚度條件下銅冷卻壁應力分布規律及掛渣穩定性

doi: 10.13374/j.issn2095-9389.2017.03.011

李峰光^1,2, ,,
張建良²

1) 湖北汽車工業學院材料科學與工程學院, 十堰 442000
2) 北京科技大學冶金與生態工程學院, 北京 100083

基金項目:

國家自然科學基金資助項目（51604103）；湖北省自然科學基金資助項目（2016CFB293）；湖北汽車工業學院博士科研啟動基金資助項目（BK201607）

詳細信息

中圖分類號: TF321.4
計量
- 文章訪問數: 813
- HTML全文瀏覽量: 269
- PDF下載量: 13
- 被引次數: 0
出版歷程
- 收稿日期: 2016-09-25

Stress distribution law and adherent dross stability of the copper cooling stave with variable slag coating thickness

LI Feng-guang^{1,2
, ,},
ZHANG Jian-liang²

1) School of Materials Science and Engineering, Hubei University of Automotive Technology, Shiyan 442002, China
2) School of Metallurgical and Ecological Engineering, University of Science and Technology Beijing, Beijing 100083, China

摘要

摘要: 根據熱彈性力學理論，建立了渣皮厚度可變的銅冷卻壁熱-力耦合應力場分布計算模型，從銅冷卻壁本體和爐渣-鑲磚界面應力分布的角度分析了煤氣溫度、冷卻制度、鑲磚材質和爐渣性質等因素對銅冷卻壁壽命及掛渣穩定性的影響規律.計算結果表明：煤氣溫度的升高使銅冷卻壁本體應力線性升高，同時掛渣穩定性減弱；銅冷卻壁本體應力值及掛渣穩定性均隨渣皮厚度增加而呈現先下降后上升的趨勢，實際生產中渣皮厚度應維持在30~60 mm之間；冷卻水流速的增大會導致銅冷卻壁本體應力值小幅上升，但可使掛渣穩定性增強；冷卻水溫的提升可小幅降低冷卻壁本體應力，但會顯著降低掛渣穩定性；鑲磚熱導率的提升和爐渣熱膨脹系數的減小均有利于降低銅冷卻壁本體應力并增強掛渣穩定性.
- 冷卻壁 /
- 掛渣 /
- 熱-力分析 /
- 應力場
Abstract: A thermal-mechanical coupling model of a copper cooling stave with variable slag coating was founded based on thermal elastic mechanics, and the influence of the gas temperature, the cooling system, the materials of insert bricks, and the properties of the slag on the stave life and the stability of the adherent dross was analyzed from the view point of the stress distribution of the stave body and the slag-brick interface. The results show that the increase of the gas temperature linearly improves the stress of stave body and reduces the stability of the adherent dross meanwhile. The stress of the stave body and the stability of the adherent dross both decrease at first and then increase when the slag coating thickness increases, and the slag coating thickness should be controlled between 30 to 60 mm. The increase of water velocity incurs tiny growth of the stress of the stave body, while the stability of the adherent dross is enhanced. The stress of the stave body is weakly reduced with the increase of water temperature, but the stability of the adherent dross decreases heavily meanwhile. The increase of the heat conductivity of insert bricks and the decrease of the heat expansion coefficient of the slag significantly reduce the stress of the stave body and enhance the stability of the adherent dross.
- cooling stave /
- adherent dross /
- thermal mechanical analysis /
- stress field

HTML全文

參考文獻(4)

[1]	Ganguly A, Reddy A S, Kumar A. Process visualization and diagnostic models using real time data of blast furnaces at Tata Steel. ISIJ Int, 2010, 50(7):1010
[2]	Yeh C P, Ho C K, Yang R J. Conjugate heat transfer analysis of copper staves and sensor bars in a blast furnace for various refractory lining thickness. Int Commun Heat Mass Transfer, 2012, 39(1):58
[5]	Zhang H S, Ma H B, Chen J, et al. The practice of copper cooling stave application for Shougang No. 2 BF//Proceedings of the 5th International Congress on the Science and Technology of Ironmaking. Shanghai, 2009:887
[7]	Zuo H B, Zhang J L, Li F G. Damage reason analysis of copper cooing stave//Materials Science and Technology Conference and Exhibition 2013. Montreal, 2013:574
