Analysis and compensation of stray parameters in high-voltage pulse generator circuits

1. Institute of Robotics and Automatic Information System, Nankai University, Tianjin 300350, China;
2. Tianjin Key Laboratory of Intelligent Robotics, Tianjin 300350, China

摘要: 在陡脈沖發生器電路中,雜散參數不僅影響輸出波形,還影響著系統的穩定和電路元器件的安全.為了提高輸出波形的質量,抑制輸出脈沖的振蕩,保證元器件長期可靠的運行,需要對電路中雜散參數進行有效的分析和補償.本文通過對脈沖的實際輸出波形進行分析,建立了陡脈沖發生器電路的雜散參數模型,總結出一種分析和補償陡脈沖發生器電路中雜散參數的方法.模型的仿真結果精確地反映了實際波形,加入補償環節后的電路實現了輸出波形的無過沖.
- 陡脈沖發生器 /
- 參數 /
- 補償 /
- 電路分析
Abstract: In a pulse generator circuit,the output and stability of the system are affected by stray parameters. In order to improve the quality of the output waveform,restrain the oscillation of the output and ensure components long-term reliable operation,it is necessary to analyze and compensate stray parameters in the pulse generator circuit. Through analyzing the actual waveform of the output,a stray parameter module for the pulse generator circuit and a new method to analyze and compensate stray parameters in the pulse generator circuit are introduced in this paper. Simulation results reflect the actual waveform accurately and no overshoot of the output is achieved after joining the compensation circuit.
- pulse generators /
- parameters /
- compensation /
- circuit analysis
