軸向流吸附器內部流場特性

王浩宇; 劉應書; 吳義民; 鄭新港

doi:10.13374/j.issn2095-9389.2016.04.018

軸向流吸附器內部流場特性

doi: 10.13374/j.issn2095-9389.2016.04.018

1. 北京聯合大學生物化學工程學院, 北京 100023;
2. 北京科技大學機械工程學院, 北京 100083;
3. 中國科學院過程工程研究所, 北京 100190

基金項目:

國家自然科學基金資助項目(51306017)

北京市自然科學基金資助項目(3144032)

北京高等學校青年英才計劃資助項目(YETP1748)

詳細信息

通訊作者:
王浩宇,E-mail:jdthaoyu@buu.edu.cn

中圖分類號: TQ028.1⁺5
計量
- 文章訪問數: 231
- HTML全文瀏覽量: 34
- PDF下載量: 11
- 被引次數: 0
出版歷程
- 收稿日期: 2016-01-25
- 網絡出版日期: 2021-07-10

Internal flow characteristics of axial flow absorbers

1. School of Biochemical Engineering, Beijing Union University, Beijing 100023, China;
2. School of Mechanical Engineering, University of Science and Technology Beijing, Beijing 100083, China;
3. Institute of Process Engineering, Chinese Academy of Sciences, Beijing 100190, China

摘要

摘要: 以軸向流吸附器內部流場為研究對象,采用CFD軟件對其內部氣體流動特性進行數值模擬.比較軸向流吸附器內無氣體分布器、僅加裝單一多孔板氣體分布器、加裝多孔板氣體分布器與單級擋板相結合等3種方式對吸附器內部流場均勻分布的影響.未加裝氣體分布器的軸向流吸附器內部氣流分布嚴重不均;僅加裝單一多孔板氣體分布器的軸向流吸附器內部流場的氣體流動稍有改善,但氣流分布仍不均勻;加裝多孔板氣體分布器與單級擋板相結合的方式,吸附器內部流場的氣體流動得到明顯改善.多孔板氣體分布器與單級擋板組合使用時,保持氣體分布器開孔率不變,開孔孔徑為0.003 m時氣流分布最為均勻,效果最好;保持開孔孔徑不變,氣體分布器的開孔率為0.388時氣流分布最為均勻.
- 吸附器 /
- 軸向流 /
- 流動特性 /
- 計算流體動力學 /
- 數值模擬
Abstract: The internal flow characteristics of axial flow absorbers were numerically studied by the computational fluid dynamics(CFD) method. The influences of three absorber models on the internal flow uniformity were compared: absorber without a flow distributor,absorber with a single flow distributor,and absorber with the combination of a flow distributor and a baffle. The results show that the flow is severely uneven without a flow distributor,is slightly meliorated with a single flow distributor,and is significantly improved with the combination of a flow distributor and a baffle. For the combined configuration,the best flow uniformities are obtained with the pore diameter of 0.003 m as the pore opening ratio remains unchanged and with the pore opening ratio of 0.388 as the pore diameter does not change.
- absorbers /
- axial flow /
- flow characteristics /
- computational fluid dynamics /
- numerical simulation
