Inclusions in low carbon aluminum killed steel slabs at high casting speed
-
摘要: 針對高拉速板坯連鑄生產的低碳鋁鎮靜鋼鑄坯,采用Aspex自動掃描電鏡對鑄坯表層夾雜物進行大面積的掃描分析,得到不同拉速下夾雜物的變化規律,并探究流場和S含量對夾雜物分布的影響.結果表明:隨著拉速增大,鉤狀坯殼的深度和長度逐漸減小.對拉速大于2 m·min-1的鑄坯,由于鉤狀坯殼不是很發達,鑄坯表層沒有發現大于200μm的夾雜物.鑄坯表層尺寸介于50~200μm的夾雜物主要是由凝固坯殼所捕獲,而夾雜物在凝固前沿的受力決定了夾雜物的捕獲行為.隨著拉速提高,凝固前沿的鋼液流速增加,隨著沖刷力的增加、捕獲力的減少,夾雜物被捕獲的數量減少.在高拉速連鑄下,如果鋼液中S含量較大,夾雜物受到明顯的溫度Marangoni力,會更容易被凝固坯殼捕獲.Abstract: Inclusions in the surface of low carbon aluminum killed steel slabs cast at high casting speed were analyzed by Aspex automated scanning electron microscopy in a large area. The changes in number and size of inclusions were tested at different casting speeds,and the influence of flow fields and sulfur content on the distribution of inclusions was explained in detail. It is found that when the casting speed increases,the depth and length of hooks decrease. Hooks in the slab subsurface is not obvious when the casting speed larger than 2 m·min-1,so inclusions larger than 200 μm cannot be found in the slab surface. Inclusions with the size of 50-200 μm in the slab surface are mainly entrapped by the solidified shell,and the entrapment of inclusions is influenced by forces acting on inclusions at the solidifying front. The flow velocity of molten steel increases due to increasing casting speed,then the washing force becomes large and the entrapping force becomes small,and therefore the number of entrapped inclusions decreases. If the sulfur content in the steel is high at high casting speed,inclusions will be easily entrapped by the solidified shell due to the thermal Marangoni force acting on inclusions obviously.
-
Key words:
- low carbon steel /
- continuous casting /
- slabs /
- inclusions
-
