Failure analysis of 22Si2MnCrNi2MoA drilling rods
-
摘要: 運用金相觀察、掃描電鏡觀察和能譜定量分析等實驗手段,從組織狀態、夾雜物、斷口形貌等方面分析了22Si2MnCrNi2MoA釬桿內螺紋處斷裂原因,同時對其疲勞裂紋起源和擴展進行了探討.22Si2MnCrNi2MoA釬桿內螺紋處斷裂破壞并不是由組織異常和夾雜物引起的,而是由于22Si2MnCrNi2MoA釬桿存在明顯的壁厚不均,在高頻應力、嚴重的內外耗同時存在的應力狀態下持續工作,壁厚較薄處極易成為受力薄弱區,疲勞裂紋更傾向于在此處優先形成,從而致使壁厚較薄處優先斷裂,最終導致釬桿斷裂失效.該釬桿疲勞破壞起源于內表面,屬于多源的疲勞斷裂.起源區微觀形貌為韌窩形貌,擴展區的微觀形貌為韌窩和沿晶的混合形貌.Abstract: The fracture of a 22Si2MnCrNi2MoA drilling rod near the internal thread was analyzed in term of the microstructure, inclusions and fractograph by means of optical microscopy, scanning electron microscopy and energy dispersive spectroscopy. Fatigue crack initiation and propagation in the drilling rod were studied. It is found that the fracture of the drilling rod is not induced by the abnormal microstructure and inclusions. Instead, because the wall thickness of the drilling rod near the internal thread is obviously uneven, the area with a thinner wall thickness tends to be the weak load-bearing point under the continuous stress of high frequency, serious outside consumption and internal friction existing simultaneously. Thus fatigue cracks are likely to emerge in the area preferentially. After that, the drilling rod ruptures in the area and eventually fractures. Furthermore, this fatigue failure is originated from the inside surface of the drilling rod and it belongs to the fatigue fracture with many crack sources. The morphology of the zones around the crack sources is dimple fracture, but the morphology of the zones of crack propagation is a mixed type with dimple and intergranular fracture.
-
Key words:
- tool steel /
- drilling rods /
- failure analysis /
- fatigue damage /
- crack initiation /
- crack propagation
-
