Analysis and design of the compliant slider mechanisms
-
摘要: 采用偽剛體模型法對全柔性滑塊機構進行了變形分析,設計了一種微型全柔性滑塊機構,并主要對其中的柔性移動副進行了設計與分析,給出了該設計實例柔性移動副的等效彈簧力,進而得到微型全柔性滑塊機構偽剛體模型的分析結果.同時用有限元方法對該實例進行了仿真分析,兩種方法所得結果基本一致,表明了理論分析是正確的,該實例的設計是可行的.Abstract: The deformation of a lumped complete compliant slider mechanism was analyzed with pseudo-rigid-body model method.A micro-compliant slider mechanism was designed,in which the prismatic pair of it was designed and analyzed mainly.The equivalent spring force of slider pair of the designed sample was presented.Furthermore the result of analysis in pseudo-rigid-body model for the sample is given.Otherwise,the simulation analysis in the FEM method for the example is also given.The results obtained by the two methods are approximated. This indicates that the analysis and design methods are correct and feasible.
-
