SEM In-situ Observation on Behavior of Inclusions with Different Sizein P/M Rene95 Superalloy
-
摘要: 以典型粉末高溫合金P/M Rene95為研究對象,在掃描電鏡原位下觀察了其中尺寸不同的陶瓷夾雜物在拉伸載荷下導致裂紋萌生的過程.結果表明,在SEM原位拉伸試驗中,隨著載荷的增加,裂紋在陶瓷夾雜物處萌生.Al2O3夾雜物的尺寸不同,導致裂紋萌生的方式不同.小尺寸的夾雜物引起的裂紋萌生易于產生在夾雜物內部,即夾雜物本身開裂,產生裂紋是在基體大面積屈服之后;而大夾雜物處的裂紋則是在合金基體未屈服之前萌生,位于夾雜/基體的界面.
-
關鍵詞:
- P/M Rene95合金 /
- 夾雜物 /
- SEM原位拉伸觀察 /
- 夾雜物行為
Abstract: Special arranged experiments were designed for SEM in-situ observation on inclusion behavior in seeded P/M Rene95 superalloy at tension loading stage. Two different size Al2O3 inclusion's behavior were followed by continuous loading till to fracture. Observed results show that crack can be easily initiated at the interface of larger inclusion and matrix even at the stress level lower than yield. Crack can be also initiated in the inclusion and then propagated to the matrix. Both mechanics show the harmful effect of inclusions in P/M superalloys.-
Key words:
- P/M Rene95 /
- inclusion /
- SEM in-situ tension observation /
- behavior of inclusions
-
