An Indexing System for Phase Diagram of Aluminum Electrolyte Based on Multimedia and Internet
-
摘要: 建立一個以因特網為介質的鋁電解體系多元相圖檢索系統.該系統利用Web中的網頁制作技術,采用動畫、圖解等多媒體手段,將文獻中記錄的大量有關的相圖以交互的方式提供給用戶.該系統是鋁電解冶金培訓與咨詢系統中的相圖子系統,包括二元相圖、三元相圖、四元相圖、立體相圖等部分.與主要通過繪制等溫線或剖面圖來描述某一體系的部分特性不同,該子系統試圖利用動畫的方式來顯示相圖,使用者可以從不同的側面來研究這些相圖.Abstract: An indexing system for Phase diagram of electrolyte based on mulimedia and internet technique was introduced. By using Web technique and dynamic drawing softwares, the system may regenerate many binary ternary and quadrary component phase diagram as well as curves of properties for these systems. The system is consisting of two main functions, one is to redraw 2-D diagrams from literatures, and the second is dynamic showing of three dimensional phase diagram of electrolyte. The system can run on the Internet.
-
Key words:
- phase diagram /
- consulting system /
- internet
-
