Application of Visualized Unified Modeling Language in Blanking Part Information Modeling
-
摘要: 通過對沖模CAD/CAM特征建模的分析,結合最先進的可視化標準建模語言UML的特點,首次提出了使用可視化標準建模語言UML進行沖壓件信息模型集成的思想.闡述了沖壓零件集成信息模型的面向對象表達,為在工程領域中使用統一的標準建模語言提供基礎.Abstract: On the base of CAD/CAM product feature-based modeling analysis, a new concept combined with the characteristics of visualized Unified Modeling Language (UML), is Put forward in integrating infor-mation model for blanking part and the model is presented in the object-oriented way. The visualized UML as a new route for using a unified modeling language in the engineering field is developed.
-
