Calculation and Design for caster angle of Cardan Shaft in Skew Rolling Mill
-
摘要: 斜軋機萬向聯接軸傾角的計算比一般縱軋機復雜,而且影響其傾角大小的因素也較多。為了避免由于萬向聯接軸的滑塊嚴重磨損造成斜軋機傳動系統的沖擊和噪音等問題,必須合理地設計斜軋機的萬向聯接軸。本文介紹了斜軋機萬向聯接軸傾角的計算公式,并論述了合理設計萬向聯接軸的幾條原則。Abstract: The calculation for the caster angle of cardan shaft in the skew rolling mill is more complicated than that in general rolling mill. Furthermore the affected factors are comparatively greater for the angle of cardan shaft in the skew rolling mill. In order to prevent the slide block of cardan shaft from wearing seriously, the cardan shaft in the skew rolling mill must be rational designed. This article presents the calculating formula of the caster angle of cardan shaft and discusses principles for designing rational cardan shaft in the skew rolling mill.
-
