高溫相變儲能微膠囊研究進展

江羽; 王倩; 王冬; 趙彤

doi:10.13374/j.issn2095-9389.2020.07.21.004

高溫相變儲能微膠囊研究進展

doi: 10.13374/j.issn2095-9389.2020.07.21.004

江羽^{1, 2},
王倩^2, ,,
王冬¹,
趙彤²

1.
北京科技大學材料科學與工程學院，北京 100083
2.
中國科學院化學研究所，中國科學院極端環境高分子材料重點實驗室，北京 100190

基金項目: 中國科學院化學研究所創新培育項目（CXPY-17）

詳細信息

通訊作者:
E-mail: wangqian@iccas.ac.cn

中圖分類號: TQ316.3
計量
- 文章訪問數: 1748
- HTML全文瀏覽量: 1247
- PDF下載量: 147
- 被引次數: 0
出版歷程
- 收稿日期: 2020-07-21
- 刊出日期: 2021-01-25

Research progress of high-temperature phase change energy storage microcapsules

JIANG Yu^{1, 2},
WANG Qian^{2
, ,},
WANG Dong¹,
ZHAO Tong²

1.
School of Materials Science and Engineering, University of Science and Technology Beijing, Beijing 100083, China
2.
Key Laboratory of Science and Technology on High-tech Polymer Materials, Chinese Academy of Sciences, Beijing 100190, China

More Information

Corresponding author: E-mail: wangqian@iccas.ac.cn

摘要

摘要: 相變材料的微膠囊化能解決相變材料在相變過程中的熔融滲出問題，提高相變材料的環境適應性、拓展其應用。本文主要對300 ℃以上的高溫相變微膠囊材料的制備及其應用進行闡述，主要論述了相變材料的分類，微膠囊的合成方法，以及高溫微膠囊的研究現狀。且通過研究表明，具有高熔點、高焓值的氟化物微膠囊是一種非常有應用前景的相變材料。
- 相變材料 /
- 高溫 /
- 微膠囊 /
- 儲能 /
- 熱防護 /
- 熱管理
Abstract: In today’s world, global problems such as a shortage of fossil fuel energy, environmental pollution, and global warming are becoming increasingly serious. For the development of human society, sustainability is particularly important. Energy is the basis for human survival and promotes the development of human society. However, rapid growth in population and the global economy has led to a significant increase in energy demand. At the same time, extensive use of fossil fuels has polluted the environment and led to a shortage of fossil energy. Currently, with the continuous increase in energy consumption and development of human society, there is a pressing need to develop energy storage technology. Latent heat storage, using phase change materials that play a vital role in the field of energy storage, has been widely accepted as an effective way to improve heat energy utilization. Phase change materials provide a type of thermal energy storage that can store a large amount of latent heat through physical phase change. This heat is then released in a controlled manner within a small temperature change based on thermal energy requirements. At present, phase change materials have important applications in aerospace, industrial and agricultural production, building materials, energy and power, textile materials, highway transportation, and engine technology. Most current research on phase change materials focuses on medium- and low-temperature materials, especially those materials whose phase change temperature is lower than 100 ℃. There is less research on high-temperature phase change materials owing to the encapsulation and corrosion of such materials. The problem of performance is difficult to solve, yet high temperature phase change materials are in urgent need in some extreme high temperature environments. High-temperature phase change materials (HTPCM) can control thermal energy under extremely high temperatures. They have important prospects for application in the fields of thermal protection and thermal management in high-temperature environments such as aerospace, solar energy, etc. The microencapsulation of phase change materials can solve the problem of melt exudation of these materials during the phase change process, improve the environmental adaptability of these materials, and expand their applications. This article mainly reviewed the preparation and application of HTPCM above 300 ℃. The classification of phase change materials, the method of synthesis of microcapsules, and the preparation of high temperature microcapsules were discussed. Through research, it is found that fluoride microcapsules, with their high melting point and enthalpy value, are a promising material in the field of HTPCMs.
- phase change materials /
- high temperature /
- microcapsules /
- energy storage /
- thermal protection /
- thermal management

HTML全文

圖 1 相變材料的相變溫度(T_m)與焓值(ΔH)圖

Figure 1. Diagram of phase change temperature (T_m) and enthalpy (ΔH) of phase change materials

下載: 全尺寸圖片幻燈片

圖 2 SEM圖像顯示通過勃姆石涂層和1130 ℃的熱氧化處理組合制備的MEPCM的表面形態（a～c）和橫截面（d）^[39]

Figure 2. SEM images showing the surface morphology (a–c) and cross-section (d) of the MEPCM prepared by the combination of boehmite coating and heat oxidation treatment at 1130 ℃^[39]

下載: 全尺寸圖片幻燈片

圖 3 金屬包殼高溫相變儲熱微膠囊的光學顯微圖^[43]

Figure 3. Optical micrograph of metal cladding high-temperature phase change heat storage microcapsules^[43]

下載: 全尺寸圖片幻燈片

圖 4 高溫加熱之前和之后的NaNO₃（a）、（b）、（e）、（f）和MCP-NaNO₃（c）、（d）、（g）、（h）的照片圖像和顯微圖像^[47]

Figure 4. Photo images and micrograph images of NaNO₃ (a)(b)(e)(f), and MCP-NaNO₃ (c)(d)(g)(h) before and after heating at high temperature^[47]

下載: 全尺寸圖片幻燈片

圖 5 加熱后的微膠囊的SEM照片。（a）將沒有GO防腐蝕防漏層的LiF @ PDA @ SiO₂微膠囊從35 ℃加熱至1000 ℃；（b）將沒有SiO₂耐熱強度層的LiF @ PDA @ GO微膠囊從35 ℃加熱到1000 ℃；（c）將LiF @ GO @ SiO₂微囊從35 ℃加熱到1000 ℃；（d）從35 ℃到900 ℃進行10次熱重循環后，LiF @ GO @ SiO₂微膠囊^[50]

Figure 5. SEM micrographs of microcapsules after heating: (a) LiF@PDA@SiO₂ microcapsules without GO anti-corrosion leakage-proof layer being heated from 35 ℃ to 1000 ℃; (b) LiF@PDA@GO microcapsules without SiO₂ heat-resistant strength layer being heated from 35 ℃ to 1000 ℃; (c) LiF@GO@SiO₂ microcapsules being heated from 35 ℃ to 1000 ℃; (d) LiF@GO@SiO₂ microcapsules after thermo-gravimetric circulation 10 times from 35 ℃ to 900 ℃^[50]

下載: 全尺寸圖片幻燈片

圖 6 1050~1150 ℃ 220次充放電循環后銅膠囊橫截面形態的SEM圖像^[52]

Figure 6. SEM image of the cross-sectional morphology of the copper capsule after 220 charge–discharge cycles from 1050–1150 ℃^[52]

下載: 全尺寸圖片幻燈片

表 1 高溫相變材料的熔點和焓值

Table 1. Melting temperature and heat of fusion of high-temperature phase change materials

Material	Melting temperature / ℃	Heat of fusion / (J·g^–1)	Material	Melting temperature / ℃	Heat of fusion / (J·g^–1)
NaNO₃	307	172	Mg	651	372.6
RbNO₃	312	31	Al	660.1	393.6
Cd	320.9	54	FeCl₂	677	337.9
NaOH	323	170	LiH	688	2678
KNO₃	333	266	Li₂MoO₄	703	281
Zn/Mg（52/48）	340	180	MgCl₂	714	454
KOH	380	149.7	Li₂CO₃	732	509
Zn/Al（96/4）	381	138	K	759	60.7
CsNO₃	409	71	KCl	771	353
Zn	419	113	NaCl	800	492
AgBr	432	48.8	LiBO₂	845	504.7
Mg/Cu/Zn（60/25/15）	452	254	LiF	848	1080
LiI	458	109	Cu/P/Si(83/10/7)	840	92
LiOH	462	433.4	Na₂CO₃	854	275.7
PbCl₂	501	78.7	KF	857	452
Al/Cu/Mg/Zn(54/22/18/6)	520	305	ZnF₂	872	400
SrI₂	527	57	K₂CO₃	897	235.8
Al/Cu(66.92/33.08)	548	372	Si/Mg(56/44)	946	757
LiBr	550	203	NaF	996	794
Ca(NO₃)₂	560	145	NaMgF₃	1022	670
Al/Cu/Si(65/30/5)	571	422	KCaF₃	1070	460
Ba(NO₃)₂	594	209	KMgF₃	1072	710
Sr(NO₃)₂	608	221	Cu	1083	205.2
LiCl	610	441	Na₂SiO₃	1088	424
CsI	629	96	MgF₂	1263	930
MgI₂	633	93	CaF₂	1418	391
CsBr	638	105	CaSO₄	1460	203
RbI	646	104	Fe	1535	314
SrBr₂	650	41	SrSO₄	1605	196

下載: 導出CSV
