NC–UHPC組合梁抗沖擊性能的數值研究

Numerical study on impact resistance of NC–UHPC composite beam

  • 摘要: 超高性能混凝土(UHPC)材料已成為極具前景的高性能材料,并在沖擊和爆炸等防護工程領域中取得了良好的效果. 對于普通鋼筋混凝土(NC)梁在受到沖擊荷載時較易發生局部沖剪破壞,而純UHPC梁雖可改善其沖擊性能,但高昂的造價限制了其進一步的應用. 為了實現結構抗沖擊性能和經濟的平衡,提出UHPC局部替換和包裹的方案改善鋼筋混凝土梁的抗沖擊性能. 本文設計了NC梁、UHPC梁和NC–UHPC組合梁等不同的研究工況,然后對比分析各個試件的抗沖擊性能. 結果表明:相比普通鋼筋混凝土梁,UHPC局部替換方案可以有效的避免梁的局部沖剪破壞,而UHPC包裹在沖擊荷載下梁的破壞模式由沖剪破壞轉變為彎曲破壞,兩種方案均可有效的減少梁跨中的峰值位移和殘余位移;UHPC局部替換相較于包裹方案,梁的跨中峰值位移和殘余位移較小,且具有更高的跨中承載能力,在實際過程中建議UHPC局部替換長度取大于2倍梁高以避免局部沖剪破壞.



    Abstract: Ultrahigh-performance concrete (UHPC) has become the most promising high-performance material, and has achieved excellent application in the field of impact and explosion protection engineering. Normal reinforced concrete (NC) beams subjected to impact load are prone to local punching shear failure. However, although the impact performance can be improved using UHPC beams, their application is limited by high costs. To achieve impact resistance at a lower cost, this work proposes a design scheme for locally replacing and wrapping NC beams with UHPC, with the aim of improving the impact resistance of NC beams. In this study, differing research conditions were employed (NC, UHPC, and NC–UHPC composite beams), and the impact resistance of specimens was compared and analyzed. Numerical models of NC and UHPC beams under impact loads were first established to verify the reliability of the modeling method, which is contact method, load application, initial velocity, boundary conditions, etc. The NC, UHPC, and NC–UHPC composite beam models were then established, and the impact performances of different NC–UHPC beam combinations were analyzed. The results revealed that compared with NC beams, the UHPC local replacement scheme effectively avoided local punching shear failure of beams. Under impact load, bending and shear cracks occurred on both sides, and the damage degree on both sides decreased with the increase of the local replacement length. For the UHPC wrapping, the failure mode of the beam changed from punching shear failure to bending failure. With an increase in UHPC thickness, the damage degree of the beam span increased, and it gradually reached that of the pure UHPC beam. Furthermore, both schemes effectively reduced peak displacement and residual displacement in the mid-span. Compared with the UHPC wrapping scheme, the peak displacement and residual displacement in the mid-span of the UHPC local replacement beam were reduced, and the mid-span bearing capacity was improved. Thus, we recommend that a local replacement length of more than twice the beam height should be selected to avoid the occurrence of local punching shear failure.



/
