基于速度調節與路徑跟蹤的差動機器人運動控制

張俊娜; 白國星

doi:10.13374/j.issn2095-9389.2022.08.14.003

基于速度調節與路徑跟蹤的差動機器人運動控制

doi: 10.13374/j.issn2095-9389.2022.08.14.003

張俊娜^1,,
白國星^2, ,

1.
山西機電職業技術學院，長治 046011
2.
北京科技大學機械工程學院，北京 100083

基金項目: 國家重點研發計劃資助項目（2018YFE0192900）；中國博士后科學基金資助項目（2022M710354）；中央高校基本科研業務費專項資金資助項目（FRF-TP-20-052A1）

詳細信息

通訊作者:
E-mail: gxbai@ustb.edu.cn

中圖分類號: TP242
計量
- 文章訪問數: 343
- HTML全文瀏覽量: 164
- PDF下載量: 113
- 被引次數: 0
出版歷程
- 收稿日期: 2022-08-14
- 網絡出版日期: 2023-01-12
- 刊出日期: 2023-09-25

Motion control of differential robot based on speed adjusting and path tracking

ZHANG Junna^1
,,
BAI Guoxing^{2
, ,}

1.
Shanxi Institute of Mechanical and Electrical Engineering, Changzhi 046011, China
2.
School of Mechanical Engineering, University of Science and Technology Beijing, Beijing 100083, China

More Information

Corresponding author: E-mail: gxbai@ustb.edu.cn

摘要

摘要: 差動機器人是一種常見的移動機器人，在倉儲、農業等行業的應用十分廣泛。針對縱向速度接近最大值時差動機器人跟蹤參考路徑的能力與保持縱向速度的能力之間存在沖突的問題，從差動機器人縱向速度與轉彎曲率之間的映射關系出發，提出了基于預瞄信息的速度調節控制器，并提出了配套的基于非線性模型預測控制的路徑跟蹤控制器，形成了基于速度調節與路徑跟蹤的差動機器人運動控制系統。仿真與實驗結果表明，提出的運動控制系統可以在差動機器人的縱向速度設定值較高時主動調節縱向速度，保障較高的路徑跟蹤控制精確性，其中位移誤差的絕對值不超過0.0499 m，航向誤差的絕對值不超過0.0726 rad，相比無速度調節的運動控制系統，該系統可將位移誤差和航向誤差的最大絕對值分別減少達97.57%和45.04%。
- 差動機器人 /
- 無人駕駛 /
- 運動控制 /
- 速度調節 /
- 路徑跟蹤
Abstract: A differential robot is a typical mobile robot widely used in storage, agriculture, and other industries. The motion control of differential robots, including longitudinal and lateral control, is a current research hotspot. To date, researchers have not paid much attention to the interaction between longitudinal and lateral control of differential robots. However, the conflict between the ability to track the reference path and maintain the longitudinal speed at its maximum value is a critical issue that limits the operational efficiency of the differential robot. To solve this problem, a mapping relationship between the longitudinal speed and the turning curvature is analyzed. The mapping relationship is established when the maximum value of the longitudinal speed is known, i.e., the feasible upper limit of the longitudinal speed that can guarantee the steering ability of the differential robot is inversely proportional to the curvature of the trajectory. From this mapping relationship, a speed-adjusting method is proposed based on the preview information. This speed-adjusting method consists of two steps. First, the smaller value between the upper limit of the feasible longitudinal speed in a certain preview distance and the set value of the longitudinal speed are taken as the desired longitudinal speed. Second, a control law is established based on the deviation between this desired and current longitudinal speed. Additionally, a path-tracking method that cooperates with the above-mentioned speed-adjusting method is proposed. The theoretical basis of this path-tracking method is a nonlinear model predictive control. The prediction model used in this control method is derived from a kinematic model with longitudinal speed as a time-dependent parameter. Finally, a differential robot motion control system is formed based on speed adjusting and path tracking. The simulation and experimental results show that the proposed motion control system can actively adjust the longitudinal speed when the set value of the longitudinal speed of the differential robot is high and ensure high accuracy of path tracking control. Furthermore, the absolute value of the displacement and heading errors does not exceed 0.0499 m and 0.0726 rad, which are reduced by 97.57% and 45.04% compared with the motion control system without speed adjusting, respectively.
- differential robot /
- unmanned driving /
- motion control /
- speed adjusting /
- path tracking

HTML全文

圖 1 控制系統框架

Figure 1. Control system framework

下載: 全尺寸圖片幻燈片

圖 2 仿真參考路徑

Figure 2. Reference path of the simulation

下載: 全尺寸圖片幻燈片

圖 3 低設定速度仿真縱向速度

Figure 3. Longitudinal speed of the low-setting speed simulation

下載: 全尺寸圖片幻燈片

圖 4 低設定速度仿真軌跡

Figure 4. Trajectories of the low-setting speed simulation

下載: 全尺寸圖片幻燈片

圖 5 低設定速度仿真軌跡局部放大

Figure 5. Local zoom-in of the trajectories of the low-setting speed simulation

下載: 全尺寸圖片幻燈片

圖 6 低設定速度仿真位移誤差

Figure 6. Displacement error of the low-setting speed simulation

下載: 全尺寸圖片幻燈片

圖 7 低設定速度仿真航向誤差

Figure 7. Heading error of the low-setting speed simulation

下載: 全尺寸圖片幻燈片

圖 8 高設定速度仿真縱向速度

Figure 8. Longitudinal speed of the high-setting speed simulation

下載: 全尺寸圖片幻燈片

圖 9 高設定速度仿真軌跡

Figure 9. Trajectories of the high-setting speed simulation

下載: 全尺寸圖片幻燈片

圖 10 高設定速度仿真軌跡局部放大

Figure 10. Local zoom-in of the trajectories of the high-setting speed simulation

下載: 全尺寸圖片幻燈片

圖 11 高設定速度仿真位移誤差

Figure 11. Displacement error of the high-setting speed simulation

下載: 全尺寸圖片幻燈片

圖 12 高設定速度仿真航向誤差

Figure 12. Heading error of the high-setting speed simulation

下載: 全尺寸圖片幻燈片

圖 13 實驗設備

Figure 13. Photograph of the differential robot used for the experiment

下載: 全尺寸圖片幻燈片

圖 14 實驗縱向速度

Figure 14. Longitudinal speed of the experiment

下載: 全尺寸圖片幻燈片

圖 15 實驗軌跡

Figure 15. Trajectories of the experiment

下載: 全尺寸圖片幻燈片

圖 16 實驗軌跡局部放大

Figure 16. Local zoom-in of the trajectories of the experiment

下載: 全尺寸圖片幻燈片

圖 17 實驗位移誤差

Figure 17. Displacement error of the experiment

下載: 全尺寸圖片幻燈片

圖 18 實驗航向誤差

Figure 18. Heading error of the experiment

下載: 全尺寸圖片幻燈片
